Electric Gate Control Valve, Explosion-proof, DN50-DN400
Key Specifications / Features
Hits: 0
Introducing our Electric Gate Control Valve, engineered for precise flow regulation in demanding environments. Featuring multi-turn operation and explosion-proof design, it ensures reliable performance even in hazardous conditions. With sizes ranging from DN50 to DN400 (2-16 inches) and pressure ratings from Class 150 to 2500 LB, it offers versatility for various applications. Constructed from high-grade Stainless Steel, it withstands corrosion and guarantees long-term durability. Its flanged end connections simplify installation, reducing downtime and enhancing efficiency. Trustworthy motorized operation ensures smooth and precise control, making it the ideal choice for critical industrial processes where safety and performance are paramount.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Electric Gate Control Valves
Key Features: Multi-Turn, Explosion-proof, Motorized
Size Range: 2 Inch - 16 Inch, DN50-DN400
Pressure Rating: Class 150 LB - 2500 LB, PN20-PN100
Body Material: Stainless Steel
Disc Material: Stainless Steel
Sealing Material: PTFE, EPDM
Power Supply:
Conventional: Single Phase 220v, Three-Phase 380v
Special: three-phase 400v, 415v, 660v(50Hz, 60Hz)
Working Environment:
Ambient temperature: -20°C to + 60°C (special temperature environment can be customized)
Relative humidity: 95% (at 25 ° C)
Protection level: Outdoor type and explosion-proof type are IP55 (IP65, IP67, IP68 can be provided for special order)
End Connection: Flange, Butt Welding
Applicable Media: Water, Air, Gas, Petroleum, Oil, Liquid
Product Name: Electric Gate Control Valves
Key Features: Multi-Turn, Explosion-proof, Motorized
Size Range: 2 Inch - 16 Inch, DN50-DN400
Pressure Rating: Class 150 LB - 2500 LB, PN20-PN100
Body Material: Stainless Steel
Disc Material: Stainless Steel
Sealing Material: PTFE, EPDM
Power Supply:
Conventional: Single Phase 220v, Three-Phase 380v
Special: three-phase 400v, 415v, 660v(50Hz, 60Hz)
Working Environment:
Ambient temperature: -20°C to + 60°C (special temperature environment can be customized)
Relative humidity: 95% (at 25 ° C)
Protection level: Outdoor type and explosion-proof type are IP55 (IP65, IP67, IP68 can be provided for special order)
End Connection: Flange, Butt Welding
Applicable Media: Water, Air, Gas, Petroleum, Oil, Liquid
