Pneumatic 3 Way Ball Control Valve, PN25-PN40, DN8-DN65, SS
Key Specifications / Features
hits: 4
Our pneumatic 3-Way Ball Control Valve is meticulously manufactured in China to deliver unparalleled precision and reliability. It comes in sizes DN8-DN65 with pressure ratings ranging from PN25 to PN40. The valve's robust body is crafted from aluminum extrusion and SS 316, ensuring exceptional corrosion resistance. With ISO5211 valve connection and flanged ends, it seamlessly integrates into diverse industrial applications, offering efficient operation. Featuring PTFE seals and a stainless steel ball, it guarantees dependable performance, making it perfect for precise control of acids, chemicals, and various stainless steel-compatible fluids in applications such as chemical processing and wastewater treatment.
Request a quote
Tags
Detail Information
Product Descriptions
Product Name: Pneumatic 3 Way Ball Control Valves
Size Range: DN8-DN65
Pressure Rating: PN25-PN40
Working Temperature: -20°C to +80°C
Valve Connection: ISO5211
Body Material: SS 316, Aluminum Extrusion
Ball Mateterial: SS 316
End Connection: Flange
Seal: PTFE
Thread: UNI EN 10226 thread.
Applications: Chemistry, control of acids and chemicals, treatment plants, stainless steel resistant fluid types.
Technical Details
• Full transition
• Excellent sealing at low and high pressures
• Fast 90 degree opening operation
• No need maintenance
Product Name: Pneumatic 3 Way Ball Control Valves
Size Range: DN8-DN65
Pressure Rating: PN25-PN40
Working Temperature: -20°C to +80°C
Valve Connection: ISO5211
Body Material: SS 316, Aluminum Extrusion
Ball Mateterial: SS 316
End Connection: Flange
Seal: PTFE
Thread: UNI EN 10226 thread.
Applications: Chemistry, control of acids and chemicals, treatment plants, stainless steel resistant fluid types.
Technical Details
• Full transition
• Excellent sealing at low and high pressures
• Fast 90 degree opening operation
• No need maintenance
