Pilot-operated Control Valve, 1/2-12 Inch, Class 150-600 LB
Key Specifications / Features
hits: 0
The pilot-operated control valve consists of a control valve, actuator, and a pilot for pressure setting. It is ideal for controlling differential pressure in pipes carrying non-corrosive liquids, gases, and vapors. When the downstream pressure increases, the control valve closes. Trim features include a built-in bellows with a pressure-balanced structure for high sensitivity, a compact and reliable maintenance-free design, and a standard modular construction that allows for various combined controls through different assemblies. This self-operated, straight-through valve with a piston actuator is available in sizes DN15-DN300 (1/2-12 Inch), class 150-300 LB, and is constructed from WCB or CF8 materials with flanged ends.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Pilot-operated Control Valve
Key Features: Self-operated, Straight-through, Diaphragm Actuator, Piston Actuator
Body Material: ASTM A216 WCB, ASTM A315 CF8, CF8M, CF3M
Size Range: DN15-DN300, 1/2 Inch - 12 Inch
Pressure Rating: Class 150 LB - 300 LB, PN16-PN40
Leakage class: ASME B16.104 Ⅴ(soft seal), ASME B16.104 Ⅳ(hard seal)
Flow characteristic: Quick Open
Bonnet Type: Standard, Heat Dissipation
Set Value Error: ±4%
Working Temperature: -30°C to 350°C
Trim Features:
1. Features a built-in bellows with a pressure-balanced structure for high sensitivity.
2. Compact design ensures reliable performance and is maintenance-free.
3. Utilizes a standard modular design.
4. Enables various combined controls through different assemblies.
Product Name: Pilot-operated Control Valve
Key Features: Self-operated, Straight-through, Diaphragm Actuator, Piston Actuator
Body Material: ASTM A216 WCB, ASTM A315 CF8, CF8M, CF3M
Size Range: DN15-DN300, 1/2 Inch - 12 Inch
Pressure Rating: Class 150 LB - 300 LB, PN16-PN40
Leakage class: ASME B16.104 Ⅴ(soft seal), ASME B16.104 Ⅳ(hard seal)
Flow characteristic: Quick Open
Bonnet Type: Standard, Heat Dissipation
Set Value Error: ±4%
Working Temperature: -30°C to 350°C
Trim Features:
1. Features a built-in bellows with a pressure-balanced structure for high sensitivity.
2. Compact design ensures reliable performance and is maintenance-free.
3. Utilizes a standard modular design.
4. Enables various combined controls through different assemblies.
