Pneumatic Globe Control Valve, ISO 14313, 1-24 IN, 150-1500 LB
Key Specifications / Features
Hits: 0
Introducing our Electric Actuator Valve, featuring a bolted design and compliant with API 6D, ASME B16.34, and ISO 14313 standards. Available in sizes DN25-DN600 (1-24 inches) and pressure ratings from 150 LB to 1500 LB (PN25-PN250). This valve offers automatic actuator selection and comes with pre-assembled instrumentation. It ensures easy maintenance with renewable seats and is available with both metal and soft seats. The design includes a blow-out-proof stem and strengthened stem packing as a default feature, providing reliability and durability for various industrial applications.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Pneumatic Globe Control Valve
Design Standard: API 6D, ASME B16.34, ISO 14313
Size Range: 1 Inch - 24 Inch, DN25-DN250
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
Operator: Pneumatic Actuator, Electric Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Standard, High
Leakage Class : API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
Test Standard: API 6D, API 598, ISO 14313
Fire Safe Standard: API 607, ISO 10497, API 6FA
Flow Characteristics: Equal Percentage, Linear, Quick Opening
End Connection: RF (Raised Face), RTJ (Ring Type Joint), BW (Butt Weld)
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Features:
The actuator selection is automatic.
The instrumentation on the valve is pre-assembled.
Easy maintenance.
Renewable seats.
Available with metal and soft seats.
Blow out proof stem.
Strengthened stem packing is default.
Product Name: Pneumatic Globe Control Valve
Design Standard: API 6D, ASME B16.34, ISO 14313
Size Range: 1 Inch - 24 Inch, DN25-DN250
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
Operator: Pneumatic Actuator, Electric Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Standard, High
Leakage Class : API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
Test Standard: API 6D, API 598, ISO 14313
Fire Safe Standard: API 607, ISO 10497, API 6FA
Flow Characteristics: Equal Percentage, Linear, Quick Opening
End Connection: RF (Raised Face), RTJ (Ring Type Joint), BW (Butt Weld)
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Features:
The actuator selection is automatic.
The instrumentation on the valve is pre-assembled.
Easy maintenance.
Renewable seats.
Available with metal and soft seats.
Blow out proof stem.
Strengthened stem packing is default.
