Quarter Turn Ball Control Valve, API 6D,1-42 IN,150-1500 LB
Key Specifications / Features
Hits: 2
Announcing our Quarter Turn Ball Control Valve, featuring a pneumatic actuator and compliant with API 6D, ASME B16.34, and ISO 14313 standards. Available in carbon steel with pressure ratings from Class 150 to 1500 LB, and sizes ranging from 1 to 42 inches, this valve offers RF and RTJ end connections. Its low torque requirements allow for smaller actuator selection and automatic actuator integration. The valve includes fixed lifting lugs, options for metal or soft seats, and is designed for easy maintenance. Additional features include emergency sealing fittings, a blow-out-proof stem, optional strengthened stem packing, and an optional locking device.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Quarter Turn Ball Control Valves
Design Standard: API 6D, ASME B16.34, ISO 14313
Size Range: 1 Inch - 42 Inch, DN25-DN1050
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
End Connection: RF (Raised Face), RTJ (Ring Type Joint), BW (Butt Weld)
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Flow Characteristics: Equal Percentage, Linear, Quick Opening
Operator: Pneumatic Actuator, Electric Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Standard, High
Leakage Class: API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
Test Standard: API 6D, API 598
Fire Safe Standard: API 607, ISO 10497, API 6FA
Features:
Low torque requirements allow for the selection of smaller actuators.
Automatic actuator selection.
Fixed lifting lugs integrated into the valve.
Options for metal or soft seats.
Designed for easy maintenance.
Emergency sealing fittings can be added if necessary.
Blow-out-proof stem design.
Optional strengthened stem packing.
Optional locking device.
Product Name: Quarter Turn Ball Control Valves
Design Standard: API 6D, ASME B16.34, ISO 14313
Size Range: 1 Inch - 42 Inch, DN25-DN1050
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
End Connection: RF (Raised Face), RTJ (Ring Type Joint), BW (Butt Weld)
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Flow Characteristics: Equal Percentage, Linear, Quick Opening
Operator: Pneumatic Actuator, Electric Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Standard, High
Leakage Class: API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
Test Standard: API 6D, API 598
Fire Safe Standard: API 607, ISO 10497, API 6FA
Features:
Low torque requirements allow for the selection of smaller actuators.
Automatic actuator selection.
Fixed lifting lugs integrated into the valve.
Options for metal or soft seats.
Designed for easy maintenance.
Emergency sealing fittings can be added if necessary.
Blow-out-proof stem design.
Optional strengthened stem packing.
Optional locking device.
