Three-Way Pneumatic Mixing Control Valves, DN40-DN80, SS
Key Specifications / Features
Hits: 4
Our Mixing Pneumatic Control Valves are designed for bypass or mixing applications. These 3-way valves are available in sizes from 1-1/2 to 3 inches (DN40-DN80) and have a pressure rating of PN10 (Class 150 LB). Constructed from durable carbon steel or stainless steel, they are offered with both flanged and threaded ends to suit various installation requirements. Ideal for precise control in demanding environments, these valves ensure reliability and high performance.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Three-Way Pneumatic Control Valve
Size Range: 1-1/2 Inch - 3 Inch, DN40-DN80
Pressure: PN10, Class 150 LB
End Connections: Flanged, Threaded
Body Material: Carbon Steel, Stainless Steel
Trim Materials:
SS 303 for Carbon Steel Bodied Valves
SS 316 for Stainless Steel Bodied Valves
Seat Materials: Jorcote on SST — Standard
Yoke Material: Cast Iron
Actuator: Steel
Control Ranges: 3-15 psi (0,2-1 bar); others upon request
Stem Packing: Spring loaded Teflon (to 450°F (232°C)) or Braided (above 450°F (232°C))
Service: Steam, oil, gas, air, water, chemicals
Seat Interchangeability: 1-1/2 Inch with 2 Inch
Actuator:
1-1/2 Inch & 2 Inch — 35M, 55M or 85M multi-spring, totally enclosed, field-reversible. Maximum actuator pressure: 50 psi (3,4 bar)
3 Inch — 55M or 85M multi-spring with or without posi tioner
Shutoff: ANSI Class IV
Features & Benefits
1. Minimal Deadband: The fully enclosed multi-spring actuator reduces deadband effectively.
2. Versatile Control Ranges: Configurable to accept a 3-15 psi signal or other control ranges upon request.
3. Positioner Options: Available with either a top-mounted or side-mounted positioner.
Product Name: Three-Way Pneumatic Control Valve
Size Range: 1-1/2 Inch - 3 Inch, DN40-DN80
Pressure: PN10, Class 150 LB
End Connections: Flanged, Threaded
Body Material: Carbon Steel, Stainless Steel
Trim Materials:
SS 303 for Carbon Steel Bodied Valves
SS 316 for Stainless Steel Bodied Valves
Seat Materials: Jorcote on SST — Standard
Yoke Material: Cast Iron
Actuator: Steel
Control Ranges: 3-15 psi (0,2-1 bar); others upon request
Stem Packing: Spring loaded Teflon (to 450°F (232°C)) or Braided (above 450°F (232°C))
Service: Steam, oil, gas, air, water, chemicals
Seat Interchangeability: 1-1/2 Inch with 2 Inch
Actuator:
1-1/2 Inch & 2 Inch — 35M, 55M or 85M multi-spring, totally enclosed, field-reversible. Maximum actuator pressure: 50 psi (3,4 bar)
3 Inch — 55M or 85M multi-spring with or without posi tioner
Shutoff: ANSI Class IV
Features & Benefits
1. Minimal Deadband: The fully enclosed multi-spring actuator reduces deadband effectively.
2. Versatile Control Ranges: Configurable to accept a 3-15 psi signal or other control ranges upon request.
3. Positioner Options: Available with either a top-mounted or side-mounted positioner.
