Posi-Flate Inflatable-seated Butterfly Control Valve, 1-40 Inch
Key Specifications / Features
hits: 2
Introducing our Posi-Flate Butterfly Control Valve, engineered for precision and reliability. Featuring an inflatable seated design and pneumatic operation, it ensures precise flow control and optimal performance. Constructed from durable materials such as cast iron, ductile iron, and ASTM A351 CF8, it offers exceptional strength and longevity. Available in sizes ranging from 1 to 40 inches (DN25-DN1000) and compatible with 150 LB pressure ratings, it adapts seamlessly to various industrial applications. Trust in our valve for dependable performance, durability, and precise flow regulation, enhancing the efficiency and reliability of your systems.
Request a quote
Tags
Detail Information
SPECIFICATIONS
Product Name: Posi-Flate Butterfly Control Valve
Key Feature: Inflatable Seated, Pneumatic Actuator
Body Material: Cast Iron, Ductile Iron, Aluminum, Stainless Steel, ASTM A351 CF8, CF8M, CF3M
Disc: Stainless Steel ASTM A351 CF3M, CF3, CF8M, Nylon Coated Ductile Iron, Aluminum Bronze, Double Stainless Steel, 2507, 1.4529
Stem: Stainless Steel
Seats: NBR, EPDM, PTFE, VITON
Size Range: 1 Inch - 40 Inch, DN25-DN1000
Pressure: PN16, Class 150 LB
Flange Accommodation:
EN 1092 PN 6, PN10, PN16
ASME Class 150 LB
AS 4087 PN10, PN16
JIS 5K, 10K
Product Name: Posi-Flate Butterfly Control Valve
Key Feature: Inflatable Seated, Pneumatic Actuator
Body Material: Cast Iron, Ductile Iron, Aluminum, Stainless Steel, ASTM A351 CF8, CF8M, CF3M
Disc: Stainless Steel ASTM A351 CF3M, CF3, CF8M, Nylon Coated Ductile Iron, Aluminum Bronze, Double Stainless Steel, 2507, 1.4529
Stem: Stainless Steel
Seats: NBR, EPDM, PTFE, VITON
Size Range: 1 Inch - 40 Inch, DN25-DN1000
Pressure: PN16, Class 150 LB
Flange Accommodation:
EN 1092 PN 6, PN10, PN16
ASME Class 150 LB
AS 4087 PN10, PN16
JIS 5K, 10K
